Automatic Pharma Capsule Counting Machine

Basic Info

Model NO.	CZG 50/8A
Customized	Customized
Condition	New
Warranty	1 Year
Power Supply	AC220V 50Hz 0.6kw
Compressed Air	0.5MPa
Dimension	860X1710X1800mm
Net Weight	400kg
Transport Package	Export Wooden Case
Specification	ISO
Trademark	PF
Origin	Shanghai, China
Production Capacity	600-1500PCS/Min

Product Description

Automatic Pharma Capsule Counting Machine

Feature
1. This product is applicable in pharmaceutical, food, health-care industry; it can count accurately and fill round tablet, shaped tablet, capsules, transparent soft gelatin capsules, pill or other solid drug or granular filling into container.
2. High speed. This product has 16 counting channels, 2 parallel filling ways; the maximum speed reaches 120 bottles per min.
3. The machine would give auto-alarm when the bottles are insufficient or the bottles jammed. The machine would pause. When the problems are solved, the machine can be normal work status again. It doesn't need certain people to watch it at any time.
4. Key pneumatic parts, especially integrated solenoid valve and cylinder for closing door are from Japan CKD, to ensure filling accuracy
5. Can set the quantity of the drugs (1~9999) on the touch screen. This can monitor the dropping status of drugs on the tracks at any time.

Characteristic

1.Advanced international control technology, PLC from Japan, HMI is easy to operate.

2.According to GMP regulation, parts in contact with medicine material are made of AISI316 stainless steel, machine body made of AISI304 stainless steel. Easy to disassemble, convenient to clean and maintain
3.The machine has several protection devices, during production, no-man watch is possible
4.You just need to change the lifting buttons on the touch screen when changing different height bottles

Feeding unit

Use 6 separate electromagnetic vibrator, frequency is variable, to separate granules rapidlyThe 6 separate vibrators avoid granule overlapping6 separate dust collection design, the dust is removed when granules dropped, to avoid dust contamination

Counting unit

Use IR (infrared ray) dynamic scan technology, good counting accuracyThe IR scan eye has automatic light compensation function; limit warning & shutdown function.

Technical parameter:Performance1: Automatic rejection device

Automatic Pharma Capsule Counting Machine

If incorrect counting is caused by too high speed or improper settings, an automatic rejection system will remove the incorrectly filled containers from the conveyor.

2: 6-section vibrator feeding units

Automatic Pharma Capsule Counting Machine

Use 6-section electromagnetic vibrator, frequency is variable, to separate tablets rapidly.

3: Funnel feeding structureThe funnels cover the bottleneck to make the drugs dropping into bottle rapidly.

4: Lift function:

Automatic Pharma Capsule Counting Machine

You just need to press the lift button on the touch screen when changing different height bottles.
